Quantity | Unit price |
---|---|
1 + | $291.95 |
For large volumes and customised products, add to your cart and click request a quote, orcontact usand we will respond within 2 working days.
Brand | American Drill Bushing |
---|---|
Manufacturer Part Number | 34401 |
Load Capacity | 31137.6 N |
Load Capacity | 7000 lbf |
Torque | 637.2 Nm |
Torque | 470.0 lb-ft |
Safety Factor | 5:1 |
Ring Type | Hoist |
Swivel Action | 360 Degree Swivel |
Base Height | 72.9 mm |
Base Height | 2.870 in |
Base Diameter | 98.5 mm |
Base Diameter | 3.878 in |
Ring Diameter | 31.8 mm |
Ring Diameter | 1.252 in |
Ring Inside Height | 95 mm |
Ring Inside Height | 3.740 in |
Bolt Length | 92.4 mm |
Bolt Length | 3.638 in |
Thread Size | M30 x 3.50 |
Overall Width | 171.5 mm |
Overall Width | 6.752 in |
Overall Height | 234.1 mm |
Overall Height | 9.217 in |
Coating | Black Oxide |
