Quarter Turn Cam Latches - Product Guide

A quarter turn cam latch can be found just about anywhere, including homes and factories. They can function as clamps or locks that help secure protected areas and enclosures. In this guide, we will look at the uses of quarter turn cam latches, the forms they come in, as well as their mode of operation.

In this article we will take a closer look at:

1. What are Quarter Turn Cam Latches?
2. What are They Types of Quarter Turn Cam Latches?
3. How Does a Quarter Turn Cam Latch Work?
4. Summary

What are quarter turn cam latches?

For the most part, a quarter turn cam latch functions as a locking mechanism that’s mounted on doors, panels, and drawers. You can find these components in switch boxes, access panels, lockers, and hatches. Comprising a housing, insert, and cam, quarter turn latches are durable and can be used across a wide range of equipment, from office furniture to military hardware.

Quarter turn cam latches get their name from the fact that they require a key, handle, or knob to turn a pawl 90 degrees in order to latch. For added strength, quarter turn receptacles or fasteners are usually added.

Quarter turn cam latches come in either quarter turn lock or non-locking varieties. Another variety is known as a compression latch which operates the same way. The only difference is that this type of latch requires an additional quarter turn to compress a gasket between the panel and the frame to create an airtight seal.

The latches come in several options for different materials and handle constructions. You can choose between a chrome plated and stainless steel quarter turn lock. The handles are made from nylon or plastic polyamide material that can withstand high temperatures and moisture. There are also a variety of finishes to choose from, including black powder coated, die-cast zinc, or chrome plated.

What are the types of quarter turn cam latches?

Quarter turn cam latches come in a variety of types that are ideal for a number of different applications, equipment, and industries. In this section, we will look over the various types of lockable and non-lockable quarter turn latches.

Light Duty

Light-duty latches are preferred for cabinets and other fixtures. They also work well for tool boxes, compartments, and other portable storage equipment. They usually come with a L-handle that’s easy to grip and manipulate.

Adjustable, Self-Adjusting and Non-Adjustable

If you are looking for a cam latch with an adjustable grip, look towards an adjustable cam latch that’s easy to install. The height for this latch can be adjusted and fixed to any desired position.

Tool-Operated

Consisting of low-profile swing handles, tool-operated cam latches can be used for indoor and outdoor applications. They typically consist of a key lock, and some varieties may have a wing knob with padlock fittings.

Quarter Turn Cam Latches with Slotted or Hex Inserts

For applications that require quick and precise assembly and disassembly, opt for quarter turn latches with slotted or hex inserts. These can be installed using a washer and plungers.

How does a quarter turn cam latch work?

A quarter turn cam latch uses a sophisticated mechanism that allows it to catch on a frame. For a full view of how these essential components work, watch the video below:

Summary

Are you in the market for quarter turn cam latches? If so, make Reid Supply the first stop on your search. Our catalog features a wide range of cam latches and cam handles that are ideal for residential, commercial, and industrial applications. For more product guides, check out our Industry News page.
